The Agco Spra-Coupe 4660 Self-Propelled Sprayer, represents a pinnacle of agricultural innovation, designed for farmers seeking precision, efficiency, and reliability in their spraying operations.
Engineered with advanced features and robust construction, the Spra-Coupe 4660 delivers superior performance across a variety of terrains and crop types.
Agco Spra-Coupe 4660 Boom
| Max Boom Width | 80 ft (24 m) |
| Min Boom Width | 60 ft (18 m) |
| Max Adjustable Height | 76 in (193 cm) |
| Min Adjustable Height | 21 in (53 cm) |
| Number of Sections | 3 |
Agco Spra-Coupe 4660 Dimensions
| Overall Length | 19 in (47 cm) |
| Tire Size | Front – 9-24 8 ply, Rear – 320/85R24 12 ply |
| Transport Width | 11 ft (3 m) |
| Wheelbase | 11 ft (3 m) |
Spra-Coupe 4660 Engine Specs
| Engine Model | Perkins 1104D |
| Gross Power | 125 hp (93 kw) |
| Power Measured @ | 2200 rpm |
| Gross Torque | 366 lbs ft (496 nm) |
| Displacement | 269 cu in (4,4 L) |
| Number of Cylinders | 4 |
| Aspiration | Turbocharger |
| Emission Tier Level | Tier III |
| Fuel Type | Diesel |
Spra-Coupe 4660 Operating Specs
| Solution Tank Capacity | 400 gal (1,514 l) |
| Fuel Capacity | 44 gal (167 l) |
| Engine Oil Capacity | 2 gal (9 l) |
| Transmission Fluid Capacity | 1 gal (3 l) |
| Operating Weight | 13,823 lbs (6,270 kg) |
Agco Spra-Coupe 4660 Transmission
| Max Speed | 19 mph (30 kph) |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 1 |
| Transmission Type | BorgWarner T-5, 5-Speed manual Allison® 2100RDS 5-speed automatic (optional) |
This sprayer boasts a powerful engine, ensuring consistent and dependable operation, while its high-capacity tank minimizes refill downtime, allowing for extended work periods. The 4660’s sophisticated control systems provide precise application rates and coverage, reducing chemical waste and promoting optimal crop health.
Key specifications of the Agco Spra-Coupe 4660 include a user-friendly cab with intuitive controls, exceptional maneuverability, and durable components built to withstand the rigors of intensive agricultural use. Whether tackling broad acreages or more intricate field layouts, the Spra-Coupe 4660 is designed to enhance productivity and ensure accurate, efficient spraying, making it an invaluable asset for modern farming operations.
