The Toro Multi Pro 5700-D Turf Sprayer is engineered to deliver precision and efficiency for large turf applications. Featuring a robust 4-cylinder diesel engine, this sprayer provides reliable power and performance to handle demanding spraying tasks.
The Multi Pro 5700-D is equipped with advanced spray system technology, ensuring even and accurate application of chemicals.
Toro Multi Pro 5700-D Boom Specs
| Min Boom Width | 19 ft (6 m) |
| Number of Sections | 3 section x 7′ (2.0 m) working width |
| Nozzle Spacing | 20 in (51 cm) / 110° extended range flat fan spray tips, quick-disconnect with diaphragm check valves |
| Number of Nozzles | 11 (Drift reduction, quick-disconnect with diaphragm check valves Turret style) |
| Boom Assembly | Break-away fore and aft Triangular truss open boom Bi-directional break-away Cross for strorage and transport Electric boom lift kit standard |
Toro Multi Pro 5700-D Dimensions
| Ground Clearance | 1 ft (0 m) |
| Overall Length | 13 in (33 cm) |
| Tire Size | Front 23 x 10.5-12, Rear 26.5×14-12 |
| Transport Height | 8 ft (2 m) |
| Transport Width | 6 ft (2 m) |
| Wheelbase | 7 ft (2 m) |
Toro Multi Pro 5700-D Engine Specs
| Engine Model | Kubota V1505-E3B |
| Displacement | 91 cu in (1.49 L) @ 3000 rpm |
| Gross Power | 36 hp (26 kw) |
| Number of Cylinders | 4 |
| Oil capacity | 5 gal (4.7 L) |
Multi Pro 5700-D Operating Specifications
| Solution Tank Capacity | 300 gal (1,136 l) |
| Drive-on weight | 2,700 lbs (1,225 kg) |
| Shipping weight | 2,700 lbs (1,225 kg) |
| Empty vehicle | 2,700 lbs (1,225 kg) |
| Full w/operator | 5,600 lbs (2,540 kg) |
| MGVW* | 6,390 lbs (2,899 kg) |
| Fuel Capacity | 11 gal (40 l) |
* Maximum Gross Vehicle Weight in utility vehicle industry
Toro Multi Pro 5700-D Transmission
| Max Speed | 10 mph (16 kph) |
| Transmission Type | Hydrostatic |
Its durable construction and ergonomic design offer exceptional operator comfort and ease of use, making it a trusted choice for professionals seeking dependable and high-quality spraying equipment.
The Toro Multi Pro 5700-D Turf Sprayer is designed to enhance productivity and deliver superior results on every job.
