The Bobcat B32V, B35V, B32S, and B35S backhoe attachments are designed to enhance the versatility and performance of Bobcat Compact Track Loaders (CTL) and Skid Steer Loaders (SSL). These backhoe attachments are ideal for a variety of applications, including digging, trenching, and material handling. Compatible with a wide range of Bobcat compact loaders, these backhoe attachments can be quickly and easily mounted, allowing operators to switch between tasks efficiently.
With digging depths ranging from 2998 mm to 3332 mm, these attachments provide the reach and power needed for deep excavation projects. High bucket and arm cylinder forces ensure powerful digging capabilities, making these attachments suitable for tough job site conditions.
Bobcat B32V, B35V, B32S, B35S Backhoe Attachment Specs
| B32V | B35V | B32S | B35S | |
|---|---|---|---|---|
| Part Number | 7396283 | 7400303 | 7416547 | 7416552 |
| Digging Depth | 121.9 in (3095 mm) | 131.2 in (3332 mm) | 118.0 in (2998 mm) | 127.4 in (3235 mm) |
| Bucket Cylinder Force | 3597.6 lbf (1600 daN) | 3597.6 lbf (1600 daN) | 3597.6 lbf (1600 daN) | 3597.6 lbf (1600 daN) |
| Arm Cylinder Force | 2549.1 lbf (1134 daN) | 3328.9 lbf (1480 daN) | 2549.1 lbf (1134 daN) | 3328.9 lbf (1480 daN) |
| Digging Reach | 154.6 in (3927 mm) | 159.7 in (4057 mm) | 150.8 in (3830 mm) | 155.9 in (3960 mm) |
| Hook-up System | Klac™ | Klac™ | Pin-on* | Pin-on* |
| Weight | 1620.6 lb (735 kg) | 1807.8 lb (820 kg) | 1565.3 lb (710 kg) | 1752.0 lb (795 kg) |
| Control Kit Required | No | No | No | No |
| Working Flow | Standard | Standard | Standard | Standard |
| First Use Installation Time | None | None | None | None |
Bobcat B32V
The Bobcat B32V offers a digging depth of 3095 mm, a bucket cylinder force of 1600 daN, and a weight of 735 kg.
Bobcat B35V
Provides a greater digging depth of 3332 mm, a bucket cylinder force of 1600 daN, and a weight of 820 kg.
Bobcat B32S
Features a digging depth of 2998 mm, a bucket cylinder force of 1600 daN, and a weight of 710 kg.
Bobcat B35S
Boasts a digging depth of 3235 mm, a bucket cylinder force of 1600 daN, a weight of 795 kg.
Bobcat B32V, B35V, B32S, B35S Compatibility Charts
| Model | B32V | B35V | B32S | B35S |
|---|---|---|---|---|
| Compact Track Loaders | ||||
| Bobcat T450 | X | X | ||
| Bobcat T590 | X | X | ||
| Bobcat T650 | X | X | ||
| Bobcat T770 | X | X | ||
| Bobcat T870 | X | X | ||
| Skid Steer Loaders | ||||
| Bobcat S450 | X | X | ||
| Bobcat S510 | X | X | ||
| Bobcat S530 | X | X | ||
| Bobcat S550 | X | X | ||
| Bobcat S570 | X | X | ||
| Bobcat S590 | X | X | ||
| Bobcat S630 | X | X | ||
| Bobcat S650 | X | X | ||
| Bobcat S770 | X | X | ||
| Bobcat S850 | X | X | ||
Tools for Bobcat B32V / B35V Backhoe Attachments
| Description | Part Number | Weight | Capacity |
|---|---|---|---|
| Auger, 15C Unit Drive | 6809442 | 106 kg | – |
| Auger, 15H Unit Drive | 7145345 | 91 kg | – |
| Breaker HB680 | 7113419 | 150 kg | – |
| Clay Spade Bucket, 25 cm | 7195717.K | 50 kg | – |
| Clay Spade Bucket, 30 cm | 7195728.K | 54 kg | – |
| Clay Spade Bucket, 35 cm | 7195731.K | 57 kg | – |
| Clay Spade Bucket, 40 cm | 7196097.K | 60 kg | – |
| Grading Bucket, STD, 120 cm | 7143789 | 112 kg | 105 L |
| Grading Bucket, STD, 140 cm | 7138642 | 129 kg | 129 L |
| Digging Bucket, STD, 23 cm | 7150069 | 48 kg | 27 L |
| Digging Bucket, STD, 25 cm | 7138636 | 49 kg | 34 L |
| Digging Bucket, STD, 30 cm | 7138637 | 54 kg | 43 L |
| Digging Bucket, STD, 40 cm | 7138638 | 60 kg | 61 L |
| Digging Bucket, STD, 45 cm | 7150070 | 64 kg | 68 L |
| Digging Bucket, STD, 50 cm | 7138639 | 67 kg | 81 L |
| Digging Bucket, STD, 60 cm | 7138640 | 71 kg | 100 L |
| Digging Bucket, STD, 70 cm | 7138641 | 78 kg | 119 L |
| Digging Bucket, STD, 80 cm | 7150071 | 85 kg | 136 L |
| Digging Bucket, HD, 30 cm | 7235042.K | 59 kg | 40 L |
| Digging Bucket, HD, 40 cm | 7235054.K | 69 kg | 60 L |
| Digging Bucket, HD, 45 cm | 7235056.K | 74 kg | 70 L |
| Digging Bucket, HD, 50 cm | 7235058.K | 78 kg | 80 L |
| Digging Bucket, HD, 60 cm | 7235060.K | 89 kg | 100 L |
| Digging Bucket, HD, 70 cm | 7235062.K | 100 kg | 120 L |
| Digging Bucket, HD, 75 cm | 7235094.K | 104 kg | 131 L |
| Digging Bucket, HD, 80 cm | 7235064.K | 109 kg | 140 L |
| Digging Bucket, HD, 90 cm | 7158700.K | 120 kg | 162 L |
| Skeleton Bucket, 70 cm | 7189656.K | 115 kg | – |
| Skeleton Bucket, 80 cm | 7189657.K | 127 kg | – |
| Skeleton Bucket, 90 cm | 7189658.K | 139 kg | – |
| Tilt Bucket, 105 cm | 7184277.K | 168 kg | 120 L |
| Tilt Bucket, 120 cm | 7184278.K | 179 kg | 139 L |
Tools for Bobcat B32S / B35S Backhoe Attachments
| Model | Part Number | Weight | Capacity |
|---|---|---|---|
| Digging Bucket, STD, 30 cm | 7423374 | 39 kg | 32 L |
| Digging Bucket, STD, 45 cm | 7423375 | 49 kg | 47 L |
| Digging Bucket, STD, 60 cm | 7423376 | 59 kg | 78 L |
| Grading Bucket, STD, 100 cm | 7423377 | 62 kg | 86 L |
Built with robust materials and a sturdy design, the B32V, B35V, B32S, and B35S attachments are engineered for long-lasting performance and reliability. The Klac™ and Pin-on hook-up systems enable quick and secure attachment to the loader, minimizing downtime and maximizing productivity.
These backhoe attachments are perfect for various tasks, including: excavation and trenching; utility and electrical work; landscaping and site preparation; material handling and loading. With these powerful and versatile backhoe attachments, Bobcat compact loaders can tackle a wide range of projects with ease and efficiency.
