The Sany SY365H Mining Excavator is a powerful and versatile machine designed to meet the demanding needs of mining operations. Engineered with advanced technology and built for durability, the SY365H offers exceptional performance, efficiency, and reliability in tough working conditions. Equipped with a robust engine, impressive digging capabilities, and a range of features that enhance productivity and operator comfort, this excavator is a reliable partner for heavy-duty mining tasks.
Its design focuses on maximizing operational efficiency while minimizing downtime, making it an ideal choice for mining professionals seeking a high-performance excavator. With a fuel tank capacity of 540.0 liters, the SY365H is designed for extended operational periods without frequent refueling, maximizing productivity. The resiliently mounted track rollers and high-tensile-strength steel construction of the track roller frame provide durability and longevity, even in harsh working conditions.
Sany SY365H Engine Specifications
| Displacement | 0.24 gal (8.9 L) |
| Max. torque | 895 lb·ft (1213 N·m) at 1500 rpm |
| Rated power | 284 HP (212 kW) at 2000 rpm |
Sany SY365H Operation Range Specs
| Max. digging depth | 23’11” (7290 mm) |
| Max. digging height | 32’3″ (9820 mm) |
| Max. dumping height | 23’5″ (7150 mm) |
| Max. vertical digging depth | 21’3″ (6480 mm) |
| Min. swing radius | 14’7″ (4450 mm) |
Sany SY365H Excavator Dimensions
| Min. ground clearance | 1’10” (550 mm) |
| Tail swing radius | 10’11” (3330 mm) |
| Track length | 16’7″ (5055 mm) |
| Transport height | 11’10” (3600 mm) |
| Transport length | 36’5″ (11100 mm) |
| Transport width | 11’1″ (3390 mm) |
Undercarriage/Working Device Specifications
| Bucket capacity | 1.96 yd³ (1.5 m³) |
| Track gauge | 8’6″ (2590 mm) |
Sany SY365H Performance Specs
| Arm digging force | 37,754 lbf (168.0 kN) |
| Bucket digging force | 43,165 lbf (192.0 kN) |
| Engine oil | 7.66 gal (29.0 L) |
| Fuel tank capacity | 142.65 gal (540.0 L) |
| Gradeability | 35° |
| Hydraulic tank capacity | 89.8 gal (340.0 L) |
| Swing speed | 9.8 rpm |
| Travel speed | 2.1/32.3 mph (3.4/52 km/h) |
The Sany SY365H Mining Excavator is packed with features that cater to the specific needs of the mining industry, ensuring superior performance, efficiency, and safety. The mining excavator is powered by a high-performance engine with a displacement of 8.9 liters, delivering a rated power of 212 kW at 2000 rpm, ensuring robust performance and reliability. The engine provides a maximum torque of 1213 N·m at 1500 rpm, enabling it to handle heavy loads and challenging tasks with ease. With a maximum digging depth of 7290 mm and a maximum digging height of 9820 mm, the SY365H is designed for deep and efficient excavation.
The excavator offers a maximum dumping height of 7150 mm, allowing for efficient material handling and loading. The excavator has a transport height of 3600 mm, transport length of 11100 mm, and transport width of 3390 mm, making it easily transportable to various sites. The minimum ground clearance of 550 mm and tail swing radius of 3330 mm enhance maneuverability in tight spaces. The track length of 5055 mm and track gauge of 2590 mm provide stability and balance during operations.
With a bucket capacity of 1.5 m³, the SY365H can handle substantial loads, improving productivity in material handling. The arm digging force of 168.0 kN and bucket digging force of 192.0 kN ensure efficient and powerful excavation. The excavator offers a swing speed of 9.8 rpm and travel speeds of 3.4/52 km/h, enhancing operational efficiency and reducing cycle times.The hydraulic tank capacity of 340.0 liters ensures smooth and efficient hydraulic operations, while the swing speed of 9.8 rpm provides quick and precise movements.
The excavator’s gradeability of 35° ensures stability and safety on steep inclines, making it suitable for various terrains. The cab is designed for comfort and ergonomics, with easy-to-reach controls and excellent visibility, reducing operator fatigue and enhancing safety. The Sany SY365H Mining Excavator is engineered to deliver exceptional performance, efficiency, and reliability, making it an excellent choice for mining operations that demand the best in heavy-duty excavating machinery.
