The John Deere 6110R Tractor, part of the 6R Series Utility Tractors produced from 2015 to 2021, exemplifies the blend of power, versatility, and advanced technology that John Deere is renowned for.
Designed to meet the diverse needs of modern agricultural operations, the JD 6110R combines a robust engine, efficient transmission options, and a highly capable hydraulic system to ensure optimal performance across a range of tasks. Whether for fieldwork, loader operations, or transport, the John Deere 6110 R delivers the reliability and functionality that farmers and contractors depend on.
John Deere 6110R Tractor Dimensions
| Wheelbase | 101.58 in (2,580 mm) |
| Overall Width | 95.7 in (2,430 mm) |
| Overall Length | 178.7 in (4,540 mm) |
| Overall Height | 110.2 in (2,800 mm) |
| Ground clearance | 15.8 in (402 mm) |
| Max Weight | 19,731 lbs (8,949 kg) |
| Max Drawbar | 13,428 lbs (6,091 kg) TLS™, IVT, 600/65R38, 540/65R24, shipping fuel, front weight support |
| Base Weight | 12,059 lbs (5470 kg) Total TLS™, AQ, 600/65R38, 540/65R24, shipping fuel, front weight support |
| Max Drawbar | 5,400 lbs (2,449 kg) |
John Deere 6110R Engine Specs
| Engine Model | John Deere PowerTech PSS |
| Engine Displacement | 275 cu in. (4.5 L) |
| Rated Engine Power | 110 hp (81 kW) @ 2100 rpm |
| Max Engine Power | 119 hp (88.7 kW) |
| Max Torque | 379.84 lb-ft (515 Nm) |
| Rated PTO Power | 84 hp (62 kW) |
| Maximum PTO Power | 109 hp (80 kW) |
| Bore/Stroke | 4.19×5.00 in (106 x 127 mm) |
| Aspiration | Single turbocharger with wastegate |
| Emission Level | Final Tier 4 |
| After Treatment Type | Diesel oxidation catalyst (DOC) and selective catalytic reduction (SCR) using diesel exhaust fluid (DEF) |
John Deere 6110 R Capacities
| Fuel Tank Capacity | 51.5 gal (195 L) |
| DEF Tank Capacity | 3.4(13 L) JD Diesel Exhaust Fluid™ |
| Cooling System Tank Capacity | 5.8 gal (22 L) JDCool-Gard™ |
| Crankcase Tank Capacity | 4.2 gal (16 L) JD Plus-50™ |
| Transmission/Hydraulics | 14 gal (53 L) Hy-Gard™ PowrQuad™ PLUS 14 gal (53 L) AutoQuad™ PLUS 15.9 gal (60 L) IVT™ |
| Air-Conditioning System Capacity | 2.70 – 2.81 lb (1,225 – 1,275 g) JD R134a Refrigerant |
JD 6110R Transmission Specs
| Type | John Deere 24-speed PowrQuad Plus 40 km/h (Standard) John Deere 16-speed PowrQuad Plus 30 km/h (Optional) John Deere 24-speed AutoQuad Plus 40 km/h (Optional) John Deere 24-speed CommandQuad Plus 40 km/h (Optional) AutoPowr™/IVT™ 40 km/h (Optional) |
| Reverser | Electronic left-hand reverser |
| Creeper | Optional |
John Deere 6110R Hydraulics
| Type | Standard: Pressure compensated (PC). Optional: Pressure-and-flow compensated (PFC) system with Load Sensing function |
| Pump Rated Output Flow | 30,0 gpm (114 L/min) |
| SCV Rated Output Flow | 26,4 gpm (99.9 L/min) |
| Hydraulic System Pressure | 2900 psi (200.0 bar) |
| Number of rear SCVs | Standard: 2 ISO couplers Optional: 2 to 4 ISO couplers |
| Number of mid SCVs | Up to three |
| Joystick SCV control | Mechanical/electrical |
JD 6110R Hitch & PTO Specs
| Rear Hitch | Category 2/3N (SAE designation) |
| Max Rear Hitch Lift Capacity | Standard: 8267.3 lb (3750 kg) Optional: 11,023.1 lb (5000 kg) |
| Sensing type | Electronic lower link |
| Rear Axle Differential Lock | Electrohydraulically with oil-cooled clutch |
| Drawbar | Category 2 |
| Max Drawbar Vertical Load | Road/field use (250-mm extended): 4409.2 lb (2000 kg) Field use (350-mm extended): 3086.5 lb (1400 kg) Field use (400-mm extended): 2645.5 lb (1200 kg) |
| Rear PTO Speed | 540: 1977 rpm 1000: 1972 rpm |
| PTO Actuation | In-cab switch and external fender-mounted remote control |
| Front Hitch Lift Capacity | 9700.3 lb (4400 kg) |
| Front PTO Speed | 540: n/a 1000: 1969 rpm |
John Deere 6110R Electrical Specs
| Charging system | Alternator 200 A / 240 A (optional) |
| Battery Voltage | 12 V |
| Battery Energy Capacity | 154 Ah |
Key features of the John Deere 6110R include the John Deere PowerTech™ EWL engine, offering up to 134 hp with Intelligent Power Management (IPM), multiple transmission options including the John Deere PowrQuad™ Plus and AutoQuad™ Plus, and a comprehensive hydraulic system with customizable configurations.
The tractor also boasts advanced emissions control technologies, such as the Diesel Oxidation Catalyst (DOC) and Selective Catalytic Reduction (SCR) systems, ensuring compliance with Final Tier 4 emission standards.
Additionally, the JD 6110R offers various options for hitch and PTO, ensuring compatibility with a wide array of implements and attachments. Enhanced operator comfort and control are provided through features like the optional Mechanical Cab Suspension (MCS) and integrated AutoTrac™ guidance system.
The John Deere 6110R is engineered to provide superior performance, durability, and efficiency, making it an ideal choice for those seeking a reliable and powerful utility tractor.
