The Kawasaki Mule 4000 TRANS UTV is a robust and versatile utility vehicle designed to cater to both work and recreational needs. Engineered for durability and performance, this model provides a seamless transition between two-passenger and four-passenger configurations, making it an ideal choice for various tasks and terrains.
Whether you are managing a farm, conducting industrial operations, or embarking on an outdoor adventure, the Kawasaki Mule 4000 TRANS UTV offers the versatility, power, and reliability needed to get the job done efficiently. Its ability to adapt between different configurations and its robust construction make it a valuable asset for a wide range of applications.
Mule 4000 TRANS Engine Specs
At the heart of the Mule 4000 TRANS is a powerful 617cc V-twin engine, delivering dependable performance for demanding jobs. Its industrial-grade engine ensures reliable power, while the fuel injection system provides consistent starts and enhanced fuel efficiency.
| Engine Type | 4-stroke, 2-cylinder, OHV, 90° V-twin, Liquid-cooled |
| Displacement | 37.7 cu in (617 cc) |
| Maximum Torque | 34.7 lb-ft (47 Nm) @ 2,500 rpm |
| Bore x Stroke | 76 x 68 mm |
| Compression Ratio | 10.3:1 |
| Alternator Output (max) | 23 amp |
| Fuel System | DFI with 34mm Mikuni throttle body |
| Fuel Capacity | 6.3 gal (23.8 L) |
Kawasaki Mule 4000 TRANS Transmission
| Type | Continuously Variable Transmission (CVT) with (H,N,R) |
| Final Drive | 2WD, shaft. Dual mode rear differential with differential lock |
| Front Suspension / Wheel Travel | MacPherson Strut / 3.9 in (99 mm) |
| Rear Suspension / Wheel Travel | DeDion Axle / 2.8 in (71 mm) |
| Front Tires | 23 x 11-10 |
| Rear Tires | 23 x 11-10 |
| Steering | Rack-and-pinion |
| Front Brakes | Drum |
| Rear Brakes | Drum |
| Park Brake Type | Independent, mechanical drum |
Kawasaki Mule 4000 TRANS Dimensions
Built to withstand tough environments, the Mule 4000 TRANS features a durable chassis and a reinforced cargo bed. Its robust suspension system, coupled with substantial ground clearance, ensures smooth rides over rough and uneven terrain.
This utility vehicle is designed to handle the rigors of industrial, agricultural, and recreational use with ease.
| Overall Length | 128.5 in (326.4 cm) |
| Overall Width | 58.5 in (148.6 cm) |
| Overall Height | 75.8 in (192.5 cm) |
| Wheelbase | 85.2 in (216.4 cm) |
| Ground Clearance | 7.7 in (19.6 cm) |
| Turning Radius | 12.8 ft (3.9 m) |
| Curb Weight | 1,514.8 lb (687.1 kg) |
Kawasaki Mule 4000 TRANS Capacities
One of the standout features of the Mule 4000 TRANS is its ability to switch between two-passenger and four-passenger modes. This flexibility makes it perfect for transporting both personnel and cargo. When in two-passenger mode, the extended cargo bed provides ample space for hauling equipment, tools, and supplies, with a load capacity of up to 800 lbs.
In four-passenger mode, it offers comfortable seating for additional passengers, maintaining a balanced blend of cargo and personnel transport.
| Cargo Bed Length | 50.4 in (128 cm) 2-person / 30.3 in (77 cm) 4-person |
| Cargo Bed Width | 47.6 in (121 cm) 2 / 4 person |
| Cargo Bed Height | 11.2 in (28.4 cm) 2 / 4 person |
| Cargo Bed Load Capacity | 800 lb (362.9 kg) 2-person 401 lb (181.9 kg) 4-person |
| Payload Capacity | 1,330 lb (603.2 kg) |
| Towing Capacity | 1,200 lb (544 kg) |
| Seating Capacity | 2-4 |
Kawasaki Mule 4000 TRANS UTV Features
The Mule 4000 TRANS is equipped with electric power steering (EPS) for effortless maneuvering, even with heavy loads or on rough ground. Its digital display provides essential information at a glance, including speed, fuel level, and diagnostics, enhancing the operator’s convenience and control.
| Dash | 12V DC outlet, fuel gauge, hour meter, parking brake warning light, coolant temperature warning light |
| Lighting | 2x tail/brake lights, 2x halogen headlights |
| Colors | Bright White |
In summary, the Kawasaki Mule 4000 TRANS UTV is a versatile and dependable utility vehicle that combines powerful performance, flexible seating, and rugged durability. It is designed to meet the diverse needs of both professional and recreational users, providing exceptional value and efficiency in every task
