The Kawasaki MULE PRO-FXT 1000 LE series is designed to deliver exceptional performance, versatility, and comfort, making it an ideal choice for both work and recreational use.
This series includes four models: the PRO-FXT 1000 LE, PRO-FXT 1000 LE CAMO, PRO-FXT 1000 LE RANCH EDITION, and the Kawasaki MULE PRO-FXT 1000 PLATINUM RANCH EDITION. Each model offers a range of features tailored to meet the diverse needs of users in various environments.
Kawasaki Mule PRO FXT 1000 LE Engine Specs
All models are powered by a 999cc, 4-stroke, 3-cylinder, DOHC, liquid-cooled engine, delivering 58.1 lb-ft of torque at 3,750 rpm.
| Model | 1000 LE / 1000 LE CAMO | LE Ranch Edition / Platinum Ranch Edition |
|---|---|---|
| Engine Type | 4-stroke, 2-cylinder, DOHC, liquid-cooled, gas | 4-stroke, 2-cylinder, DOHC, liquid-cooled, gas |
| Displacement | 61 cu in (999 cc) | 61 cu in (999 cc) |
| Maximum Torque | 61.5 lb-ft (83.4 Nm) | 61.5 lb-ft (83.4 Nm) |
| Bore x Stroke | 92.0 x 75.1mm | 92.0 x 75.1 mm |
| Compression Ratio | 10.1:1 | 10.1:1 |
| Fuel System | DFI with 38 mm throttle body | DFI with 38 mm throttle body |
| Alternator Output (max) | 90 amp | 90 amp |
Kawasaki Mule PRO FXT 1000 LE Dimensions
With a length of 135.6 inches, width of 64.0 inches, and height of 79.5 inches, these vehicles offer ample space and stability.
| Model | 1000 LE / 1000 LE CAMO | LE Ranch Edition / Platinum Ranch Edition |
|---|---|---|
| Overall Length | 135.8 in (344.9 cm) | 135.8 in (344.9 cm) FXT 1000 LE Ranch Edition 140.2 in (356.1 cm) FXT 1000 Platinum Ranch Edition |
| Overall Width | 64.0 in (162.6 cm) | 64.0 in (162.6 cm) |
| Overall Height | 80.9 in (205.5 cm) | 80.9 in (205.5 cm) |
| Wheelbase | 92.3 in (234.5 cm) | 92.3 in (234.5 cm) |
| Ground Clearance | 12.6 in (32.0 cm) max, 11.6 in (29.5 cm) std | 12.6 in (32.0 cm) max, 11.6 in (29.5 cm) std |
| Turning Radius | 16.0 ft (4.9 m) | 16.0 ft (4.9 m) |
| Curb Weight | 1,913.9 lb (868.1 kg) FXT 1000 LE 1,922.8 lb (872.2 kg) FXT 1000 LE CAMO |
1,966.9 lb (892.2 kg) FXT 1000 LE Ranch Edition 2,030.8 lb (921.1 kg) FXT 1000 Platinum Ranch Edition |
Mule PRO FXT 1000 LE Transmission & Chassis
They feature a Continuously Variable Transmission (CVT) with selectable 2WD/4WD, and dual-mode rear differential with differential lock.
| Model | 1000 LE / 1000 LE CAMO | LE Ranch Edition / Platinum Ranch Edition |
|---|---|---|
| Type | Continuously Variable Transmission (CVT) with high and low range, neutral, reverse (L,H,N,R) | Continuously Variable Transmission (CVT) with high and low range, neutral, reverse (L,H,N,R) |
| Final Drive | Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock | Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock |
| Front Suspension / Wheel Travel | Double wishbone / 11.0 in | Double wishbone / 11.0 in |
| Rear Suspension / Wheel Travel | Double wishbone / 10.1 in | Double wishbone / 10.1 in |
| Front Tires | 26 x 9.00-12, radial | 26 x 9.00-12, radial |
| Rear Tires | 26 x 11.00-12, radial | 26 x 11.00-12, radial |
| Steering | Electric Power Steering (EPS), Tilt steering | Electric Power Steering (EPS), Tilt steering |
| Front Brakes | Dual Disc, 2 piston caliper | Dual Disc, 2 piston caliper |
| Rear Brakes | Dual Disc, 1 piston caliper | Dual Disc, 1 piston caliper |
| Park Brake Type | Independent, mechanical disc | Independent, mechanical disc |
Kawasaki Mule PRO FXT 1000 LE Capacities
Each model boasts a cargo bed load capacity of 999 pounds and a towing capacity of 2,000 pounds, ensuring they can handle substantial loads.
| Model | 1000 LE / 1000 LE CAMO | LE Ranch Edition / Platinum Ranch Edition |
|---|---|---|
| Fuel Capacity | 7.9 gal (29.9 L) | 7.9 gal (29.9 L) |
| Cargo Bed Length | 42.7 in (108.5 cm) 3-person 22.0 in (55.9 cm) 6-person |
42.7 in (108.5 cm) 3-person 22.0 in (55.9 cm) 6-person |
| Cargo Bed Width | 53.7 in (136.4 cm) 3-person 53.7 in (136.4 cm) 6-person |
53.7 in (136.4 cm) 3-person 53.7 in (136.4 cm) 6-person |
| Cargo Bed Height | 11.0 in (27.9 cm) 3-person 11.0 in (27.9 cm) 6-person |
11.0 in (27.9 cm) 3-person 11.0 in (27.9 cm) 6-person |
| Cargo Bed Load Capacity | 999 lb (453.1 kg) 3-person 350 lb (158.8 kg) 6-person |
999 lb (453.1 kg) 3-person 350 lb (158.8 kg) 6-person |
| Payload Capacity | 1,616.3 lb (733.1 kg) | 1,616.3 lb (733.1 kg) |
| Towing Capacity | 2,000 lb (907.2 kg) | 2,000 lb (907.2 kg) |
| Seating Capacity | 3-person (1 row), 6 person (2 row) | 3-person (1 row), 6 person (2 row) |
Kawasaki Mule PRO FXT 1000 LE Features
From the multi-function display to the electric power steering, these utility vehicles are designed for ease of use and operator comfort.
| Model | 1000 LE / 1000 LE CAMO | LE Ranch Edition / Platinum Ranch Edition |
|---|---|---|
| Dashboard | Multi-function display includes digital speedometer, fuel gauge, odometer, hour meter, clock, dual trip meters, 2WD/4WD indicator, water temperature warning indicator, oil pressure warning indicator, fuel injection warning indicator, CVT and EPS warning indicators, neutral, reverse and parking indicators, seatbelt reminder lamps | Multi-function display includes digital speedometer, fuel gauge, 2WD/4WD indicator, odometer, clock, dual trip meters, water temperature warning indicator, hour meter, oil pressure warning indicator, fuel injection warning indicator, CVT and EPS warning indicators, neutral, reverse and parking indicators, seatbelt reminder lamps |
| Lighting | 2x Halogen headlights. 2x LED headlights | 1000 LE Ranch Edition: 2x Halogen headlights. 2x LED headlights 1000 Platinum Ranch Edition: 4x LED headlights |
| Colors | FXT 1000 LE: Metallic Onyx Black, Metallic Sierra Blue FXT 1000 LE CAMO: TRUETIMBER® STRATA |
1000 LE Ranch Edition: Metallic Titanium 1000 Platinum Ranch Edition: Metallic Stardust White |
| Add-ons | Roof, Additional Front Cup Holders | 1000 LE Ranch Edition: Roof, Additional Front Cup Holders, WARN® VRX 45 Winch, Premium Seats, Self-Leveling Rear Suspension
1000 Platinum Ranch Edition: Roof, Additional Front Cup Holders, WARN® VRX 45 Winch, Premium Seats, Premium Shoulder Pads, Self-Leveling Rear Suspension, Quad LED Headlights, Brush Guard, Headlight Guards, Rear Bumper, Anti-cinch Seat Belts, Rearview Mirror, Additional Under Seat Storage Bin |
The MULE PRO-FXT 1000 LE combines powerful performance with an extensive feature set. Equipped with a robust 999cc engine, it provides the torque needed for heavy-duty tasks. This model is designed for those who require a reliable utility vehicle with a focus on functionality and comfort.
The MULE PRO-FXT 1000 LE CAMO is tailored for outdoor enthusiasts and hunters. It features a unique camo pattern that blends seamlessly into natural surroundings, making it perfect for off-road adventures. With the same powerful 999cc engine, it delivers the performance needed for rugged terrains.
The MULE PRO-FXT 1000 LE RANCH EDITION offers premium features and a stylish design, catering to users who need both utility and a touch of luxury. It includes additional amenities like a winch and premium upholstery, ensuring a comfortable and productive experience whether you’re on the job or enjoying a day out.
The MULE PRO-FXT 1000 PLATINUM RANCH EDITION stands out with its sophisticated design and top-tier features. This model is the epitome of luxury and capability, offering advanced features such as enhanced lighting, a robust roof, and an upgraded dashboard. It’s built for those who demand the best in both performance and comfort.
The Kawasaki MULE PRO-FXT 1000 series is engineered to meet the demands of various users, providing a blend of power, versatility, and premium features. Whether you need a reliable partner for tough jobs or a comfortable ride for leisure activities, these utility vehicles offer the performance and reliability you expect from Kawasaki.
